Industrial Pressure Transmitter PT-605

Industrial Pressure Transmitter | 6 Series | 4-20 m A | for multiple measuring ranges and electrical connection options

Pressure Range

0MPa~0.1MPa~10MPa

Accuracy

±0.25% FS

Output Signal

4~20mA, 0~10VDC

Process Connection

G1/4, Custom

Electrical Connection

Hirschmann

Supply Voltage

24 VDC, 10~36 VDC

Ordering & Supply

MOQ (Minimum Order Quantity): 1 pcs
Lead Time: 7-15 working days (standard)
Supply Capacity: 50,000 pcs / month
Customization: Range / Output / Thread / Material

Download Datasheet Request Quote Get Sample

Product Description

The PT-605 flush pressure transmitter features an imported sensor core and a compact stainless steel isolation structure. It offers excellent stability, a wide temperature range, and a service life of over ten million cycles. Widely used in the food and sanitary industries, it is CE certified and can directly replace well-known branded products. OEM branding is available upon request.

Product Details

Technical Parameters:

Pressure range	0MPa~0.1MPa~10MPa
Overload pressure	200%FS
Accuracy	±0.25%FS、±0.5%FS
Temperature shift	±0.02%FS/℃
Working temperature	-40~85℃
Output signal	4-20mA	0-10VDC
Power supply DC	3-5V	24V (10-36V)
Ingress	IP65
Process connection	G1/2, M20*1.5 etc. customizable
Electrical connection	Hirschmann GDM series
