Deep Dive into Pressure Sensors and Core Modules: Working Principles, Applications

Pressure sensors and core modules are critical components in modern industrial automation, the Internet of Things (IoT), and consumer electronics. The core sensing element acts as the “heart” of the sensor, determining overall system precision, stability, and longevity.

Working Principle of Pressure Sensor Core Modules Pressure cores typically operate on piezoresistive or piezoelectric principles. When external pressure is applied to the sensitive diaphragm, the strain resistors inside the core deform, changing the resistance value and converting it into a standard electrical output signal. The introduction of Micro-Electro-Mechanical Systems (MEMS) technology has driven core modules toward miniaturization, high integration, and enhanced sensitivity.

Key Application Fields

  • Industrial Automation: Used in hydraulic systems, pneumatic controls, and pipeline pressure monitoring.

  • Automotive Manufacturing: Applied in Tire Pressure Monitoring Systems (TPMS), engine oil pressure, and braking systems.

  • Medical Equipment: Precision pressure measurement in sphygmomanometers, infusion pumps, and ventilators.

  • Consumer Electronics: Altimeters and barometers in smartphones and wearable devices
